Product Details
＋
Fast ONE AHF 100A-400V, Active Harmonic Filter & Static Var Generator, 70Kvar/100 Amp, 3 Phase 3 Wire, 400VAC /-20%
For Automatic Switching of Power Factor Correction Capacitors according to changing site conditions. and for the filtering or control of Harmonic Distortion
Features
- IP40
- RS485 Comms
- IEC 654-1, UL Approved
- 1 Year Fastron Electronics Warranty
- For External Cabinet Mounting
- Control up to 6 Modules from a single HMI
Specification
| Fastron Part Number | Fast ONE AHF 100A-400V |
| Function | Reactive Power Correction & Active Harmonic Filter |
| Comms | RS485 (Optional) |
| Termination Style | Screw |
| Dimensions | 153x237x36mm |
| Weight | 1kg |
| Certification |
EN 61000-6-4:2007 A1:2011 EN 61000-6-2:2005 EN 61000-3-2:2014 EN 61000-3-3:2013 A1:2019 |
| Factory Pack Qty | 1 |
| Material of housing | PC/ABS Unflammable, according to UL 94 V-0, & Stainless Steel Painted RAL 1013 |
| Enclosure protection | IP40 |
| Safety | According to EN 61 010-1, installation category III Pollution degree 2 |
| Operating Temperature | -20...55 °C |
