Features:

• CAT III 600V Digital Multimeter
• 3.5" digit backlit LCD (max. reading 1999)
• Data hold function
• Overload protection
• Low battery indication
• Continuity & diode testing
• Battery testing: 1.5V / 9V
• Resistance measurements: up to 2000KΩ
• Manufactured & tested to EN 61010

Specifications:

• SKU: JEFDMM600V
• DC Voltage Range: 200m ~ 600V
• DC Current Range: 2000μ ~ 10A
• AC Voltage: 200 ~ 600V
• Input Impedance: 1MΩ
• Resistance: 200 ~ 2MΩ
• Continuity: <30Ω, >100Ω
• Diode Testing: 2.8V (approx)
• Test Current: 1mA
• Battery Testing: 1.5V / 9V
• Overload Protection: Both Fuses: ø5x20mm F1: Fuse, 250mA / 600V, Fast action F2: Fuse, 10A / 600V, Fast action
• Certified To: EN 61010
• Gross Weight: 0.39 kgs
